SPECIFICATIONS
Mating part 120508-XXP-FX-PM,120508-XXP-FX-PB,120508-XXP-RX-PM,120508R-XXP-A-AC,120508-XXP-A-AC,MCA08-XXPFX4,MCA08-XXPFX,MCA08-XXPRX
Contact configuration
A Code : 2,3,4,6,8 Pin
B Code : 5 Pin
Current rating 3A(2~5P); 1A(6~8P)
Voltage rating 60V(2~3P); 30V(4~8P)
Contact resistance 5m ohm Max.
Insulation resistance
Cable: ≥ 10MΩ
Connector: ≥ 100MΩ
Operating temperature -40°C ~ +80°C
Waterproof rate IP67
Material plating Contact Gold Plated,Shell Nickel Plated
